The GPON Doctor 4k7 is a compact, chipset-free tool designed for analyzing GPON FTTH protocols. It functions as a portable analyzer, connecting to a distribution fiber point within a GPON network. This device captures detailed data in both upstream and downstream directions, and it interprets all control information at PLOAM and OMCI levels.
GPON Doctor 4k7 is the ultimate solution for troubleshooting, certification, and interoperability analysis in GPON deployment. It is specifically designed to cater to the needs of GPON deployment operators, installers, and hardware manufacturers. The solution comprises GPON data acquisition hardware, a more efficient chassis/device, and software for analyzing the acquired data.
The capture equipment is designed in-house with the latest optical modules and extensive processing capabilities, guaranteeing top-level performance and dependability. It seamlessly synchronizes with the GPON fiber's upload and download link at any location and self-adjusts for long-term captures. Additionally, it efficiently extracts and deciphers Ethernet traffic from higher layers in real time, facilitating smooth service regeneration.
Features –
The GPON Doctor analyzes gathered data to figure out how the network is structured, and then checks if it follows the ITU-T G.984.x guidelines. It's designed to be user-friendly right from the start, with features like automatic timing adjustment, calibration, and an easy-to-understand interface. It's really good at spotting issues in a GPON network, pinpointing which equipment is causing the trouble, and figuring out what went wrong.
Upstream + Downstream
Analysis with Diagrams
Real-time GPON Capture
Regeneration and QoS
Real-time extraction
Applications
Laboratory & Field Operation
Validation
Analysis and Assessment
Neutral analysis and Capture
Optimizing GPON
Experience Smoother Operations and Enhanced Visibility with GPON Doctor 10k7
GPONDoctor 10K7 is a strong tool for analyzing GPON and XGSPON protocols. It can capture data going both ways (upstream and downstream) at a very detailed level. It understands and interprets various control signals like AOM, PLOAM, and OMCI. It can also extract user traffic specifically at the Ethernet layer. Additionally, it can measure optical power, identify line faults, and report them. All these features make it a great choice for tasks like troubleshooting, certification, and analyzing compatibility between different systems.
This tool is really important for making sure the network follows the rules. It checks if different systems can work together and if they meet the standards. It combines the features of GPONDoctor 9k7 and GPONDoctor 4k7 into one device. It can work in two different modes: XGS-PON and GPON.
The GPON Doctor 10K7 is a vital tool for keeping networks running smoothly. It's a portable and versatile testing device designed for GPON and XGSPON operators. Whether it's certifying, accepting, deploying, or fixing network issues, this tool is perfect for the job. It's also useful for checking that different ONU and OLT devices from various vendors work well together.
The analysis software helps users understand captured data by showing control frames. It can figure out the network layout of ONT state machines, data channels, configurations exchanged, and OMCI diagrams. It also generates graphs for analysis and bandwidth for each ONT, T-CONT, and port with high accuracy.
The GPD 10K7 is a powerful tool that combines a robust hardware capture card with advanced software. It's great at capturing both upstream and downstream data simultaneously, giving a detailed view of PON status, entities, and their connections. It also monitors bandwidth usage and any deviations from standard practices. Its capture card is designed with cutting-edge optical modules and strong processing power, making it easy to extract and decode Ethernet traffic from GEM ports, including TV and interactive applications.
Features
Link Integrity Monitor
Optical Power Meter
User traffic extraction
OMCI E/R Plots
QoS assessment
Real-time capture
GPD 10k7 in operation
Laboratory & Field use
IP Services certification
Vendor interoperability
Test ensures the compliance
FTTH acceptance
GPON & XGSPON analysis
Boost Efficiency & Reduce Downtime with Powerful GPON Doctor 9K7
The GPON Doctor 9k7 (GPD 9k5) is a dependable tool made for finding, keeping an eye on, and fixing problems in FTTH XGSPON-based networks. It's easy to carry around, runs on batteries, and tough enough to handle rough outdoor conditions. This makes it perfect for pinpointing and solving issues with protocols or IP services.
Moreover, it can check if different systems can work together smoothly and ensure that networks follow the rules. GPON Doctor 9k7 is a powerful testing tool that handles various types of management data efficiently. It's especially good at quickly analyzing multimedia services, which is perfect for telecom companies using XGS-PON technology. Whether it's setting up, fixing problems, or just keeping things running smoothly, this tool is the best. It's also useful for companies making the equipment used in these networks, helping them ensure their products meet standards and work well with others.
The analysis software reads the data it collects, allowing the user to track all control frames. It can also figure out the layout of the XGS-PON network. This includes understanding how ONTs and OLTs are set up, the data pathways that are established, the configurations that are exchanged, and diagrams that show how information flows between equipment. Additionally, it provides detailed analysis and graphs showing the bandwidth usage for each ONT on its respective T-CONT.
This device, the GPD 9k5, is perfect for keeping an eye on networks. It's got top-notch hardware, a portable battery, and great software. With it, you can monitor both incoming and outgoing data at the same time. This means you can figure out the status of different network elements, like PONs, and how they're connected. Plus, you can keep track of how much bandwidth is being used and if anything isn't following the usual pattern.
Features
The Traffic Capture feature of GPON-Doctor 9k7 takes FTTH traffic and breaks it down using ITU-T standards. It figures out how the ONT, OLT, and data channels are connected, then makes graphs showing how much bandwidth each channel is using.
